- Models:
- 815PT
- Ranges:
- 0-5 psi to 0-30,000 psi (5:1 turndown)
- Certifications:
- Unit: ATEX, CRN, Dual Seal (Canada), FM (US and Canada)
- Warranty:
- 3 Years
The 815PT smart pressure transmitter is a rugged, compact, loop-powered instrument that is ideally suited for hazardous locations and hostile environments where space is limited. The 815PT offers many industry standard outputs to meet applications where low-cost, discrete and continuous monitoring is required or preferred.
The 815PT is easily configured using HART®7 Communication Protocol and Modbus RTU Serial Communications or when setting the zero and span set points with a magnet.
- HART®7 communication protocol with 4-20 mA output
- 1-5 VDC (low-power) mode of operation output
- Modbus RTU (RS-485) serial communications
- Configurable normally open solid state switch output (SPST)
- +/-0.10% (URL) continuous output accuracy
- Compact, 316 stainless steel, explosion proof housing
- Local Indicating Display option available
- Hermetically sealed leads
- Zero and span magnetic targets located on casting
- EMC (EMI/RFI) protection
- NEMA 4X, IP66 housing
- FM and ATEX certified for hazardous locations in U.S., Canada and Europe
- Dual Seal approval available
- Absolute Pressure range options
